PZ751 Module PZ 751 H&B Contronic

H&B Contronic PZ751 Termination Plug Manufacturers ABB, Hartmann & Braun Model(s)

ABB H&B Contronic, ABB H&B Contronic 3

Estimated Shipping Size Dimensions: 4.0" x 2.0" x 4.0" (10.2 cm x 5.1 cm x 10.2 cm)

Weight: 0 lbs 3.0 oz (0.1kg ) PZ751

Cyberex® RPP features

•   UL listed current limiting branch circuit breakers

•   IP20 touch safe

•   Voltage ratings: 208/120V, 415/240V, 480/277V

•   Current ratings: 225A, 400A

•   1 to 100A branch breakers at 208V

•   1 to 25A branch breakers at 480V

•   Interrupting ratings: 35kA at 208V, 14kA at 480V

•   Main/branch breaker coordination up to 28.6kA

at 208V, 14kA at 480V

•   Insulating resin encased bus

•   Pluggable breaker with non-energized bolt on screw

Below is a side internal view of the EL mechanism and the associated anti-pumping component.

When the opening pushbutton or coils are activated the opening shaft lever pushes down on point C of the anti-pump device.

This causes the device to side down slot D in direction of arrow B.

Then the trigger portion A moves out from between the closing push-button and the closing shaft lever.

So if the closing button or signal is held active and the opening button or signal is then activated.

The trigger A will pull out from between closing shaft lever and the closing push button.

Once the open signal is released the trigger A will come to rest under the closing push-button and will

not return between the closing shaft lever and closing push-button until the button or closing command is released.

The closing push button is operated by the closing coil (MC) directly by the shaft closing device.

This allows the anti-pumping device to prohibit closing by manual or electrical means.
