ABB REF615C_E HCFDACADABC2BAN11E Feeder Protection and Control

The ABB DO630 is a robust 16-channel digital output module designed for reliable control of various industrial applications.

Offering isolated outputs and compatibility with 250VAC, it delivers precise and safe switching capabilities.

Key Features:

16 Isolated Channels: Control up to 16 independent loads with individual channel isolation, minimizing potential interference and enhancing system stability.

250VAC Compatibility: Handle a wide range of AC loads with a maximum voltage rating of 250VAC, ensuring versatility in diverse industrial settings.

Relay Contacts: Utilize reliable relay contacts for direct switching of actuators, valves, and other industrial equipment.

Compact Design: Optimize space within control cabinets with the module’s compact footprint, maximizing efficiency.

Technical Specifications:

Channel Type: Digital Output (DO)

Number of Channels: 16

Voltage Rating: 250VAC

Output Type: Relay Contacts

Applications:

Factory automation

Process control

Building automation

Machine control

Lighting control

The DO802 is an 8 channel 110 V d.c./250 V a.c. relay (NO) output

module for the S800 I/O. The maximum voltage range is 250 V and

the maximum continuous output current is 2 A. Al outputs are

individualy isolated. Each output channel consists of optical

isolation barrier, output state indication LED, relay driver, relay and

EMC protection components.

The relay supply voltage supervision, derived from the 24 V

distributed on the ModuleBus, gives a channel signal error and a

module warning signal if the voltage disappears. The error signal and

warning signal can be read through the ModuleBus. This supervision

can be enabled/disabled with a parameter.
