ABB AIM0006 2RCA021397A0001F PC BOARD
❤ Add to collection

ABB AIM0006 2RCA021397A0001F PC BOARD

+86-18144100983
kongjiangauto@163.com
wind, petroleum, chemical, natural gas, Marine, mining, aviation, electronics, steel, nuclear power, electric power, coking, air separation and so on
PLC, DCS, servo, analog, Ethernet, digital, redundant module, tension system, excitation, generator management, human-machine interface, detection card, sensor, AC drive, etc
U.S.＄8335.00
U.S.＄4912.00
Weight：3.600KG
Quantity：
(Inventory: 8)
Buy now
Add to cart
Product parameters
  • Tell:+86-18144100983
  • email:kongjiangauto@163.com
  • Application:wind/ petroleum/ chemical/ natural gas/ Marine/ mining/ aviation/ electronics/ steel/ nuclear power/ electric power/ coking/ air separation and so on
  • Series:PLC/ DCS/ servo/ analog/ Ethernet/ digital/ redundant module/ tension system/ excitation/ generator management/ human-machine interface/ detection card/ sensor/ AC drive/ etc
Feature

TIM foils or otherwise known as graphite sheet have been introduced in use in ACS800 mod

ules using EconoPACK+ IGBT as part of normal continuous improvements in the ACS800

product family. Benefits of using TIM foils in comparison to thermal grease are easier installa

tion and more durable heat transferring properties for longer periods of time. Durability par

ticularly improved in a cyclic application.

Where and how to use

TIM foils are used to transfer the heat generated in the IGBT’s to the heatsink. Full instruc

tions on how to install TIM foils is described in document delivered with TIM IGBT spare part

kits. It’s possible to use a mix of IGBT’s with thermal grease and TIM foils. In parallel con

nected R8i modules it’s also possible to use a mix of modules using TIM foils and thermal grease.

This module has 16 digital inputs. The input voltage range is 18 to 30

volt d.c. and the input current is 6 mA at 24 V. The inputs are divided

into two individualy isolated groups with eight channels and one

voltage supervision input in each group. Every input channel

consists of current limiting components, EMC protection

components, input state indication LED and optical isolation barrier.

The process voltage supervision input give channel error signals if

the voltage disappears. The error signal can be read via the ModuleBus.

Features and benefits

• 16 channels for 24 V d.c. inputs with current sinking

• Two isolated groups of 8 with voltage supervision

• Input status indicators

The input voltage range is 18 to 30 volt dc and the input current

source is 6 mA at 24 V. The inputs are divided into two individualy

isolated groups with eight channels and one voltage supervision

input in each group. Every input channel consists of current limiting

components, EMC protection components, input state indication

LED and optical isolation barrier. The process voltage supervision

input give channel error signals if the voltage disappears. The error

signal can be read through the ModuleBus.
