GE 760-P5-G5-S5-HI-A20-R-E Feeder Management Relay

Communications

The D485 Modbus to DeviceNet Converter acts as a gateway between a Modbus RTU

network and a DeviceNet network. Integration of Modbus devices into DeviceNet

networks is enabled without loss of functionality, control, and reliability, both when

retrofitting to existing equipment as well as when setting up new installations.

The D485 Modbus to DeviceNet Converter is an external DIN-rail mounted device

which provides DeviceNet network connectivity via a serial RS232/RS422/RS485 interface.

The D485 is programmed using the P485/D485 configuration cable and the

EnerVista P485/D485 Setup Software.

Connectivities

• Connects up to 10 Modbus devices to a DeviceNet network

• Contains pre-configured memory maps for specific GE Multilin devices

• Supports DeviceNet “Adapter” functionality (Profile Number 12)

• Supports Explicit and all four types of I/O

messaging formats:- Polled- Change of State (COS) - Bit strobed - Cyclic

• Supports DeviceNet baud rates 125 Kbps, 250 Kbps and 500 Kbps

• Connects to DeviceNet network using 5-pin linear DeviceNet plug

• Acts as a master to Modbus RTU devices

• Supports Modbus baud rate of 1200bps to 57600bps

• Modbus interfaces supported: RS232. RS422 RS485

• Supports up to 50 Modbus Transactions

• DIN-rail mountable

• 1024 bytes of total data exchange- 512 bytes of data to Modbus devices- 512 bytes of data to DeviceNet master

• Configured using the EnerVista P485/D485 Setup Software

• Upload common configuration files to

multiple D485 devices

• 24 VDC input power

• CE, UL and cUL certified

A Safer and Cybersecure Substation

Transmitting the instrument transformers´ measurements digitally

through optical fibers eliminates the risk of inadvertent mishandling

of the current and voltage circuits and makes the relay room a safer

work environment, eliminating hazards and reducing the risk of

personnel injury.

To ensure MU360 have all this connectivity in a cybersecure way, it

has been designed according to IEC 62443 and have all capabilities

described by SL2 of this standard, including RBAC, secure boot and

signed firmware.
