A-B 1783-ZMS16TA ArmorStratix 5700 Ethernet Managed Switches

The I/O configuration portion of the RSLogix 5000® programming software generates the

configuration data for each I/O module in the control system,

whether the module is in a local or remote chassis.

A remote chassis, also known as networked, contains the I/O module but not the module’s owner-controller.

A remote chassis can be connected to the controller via a scheduled connection on the ControlNet network or an EtherNet/IP network.

RSLogix 5000 configuration data is transferred to the controller during the program

download and later transferred to the appropriate I/O modules.

I/O modules in the local chassis, and modules in a remote chassis connected via the EtherNet/IP network,

or unscheduled connections on the ControlNet network, are ready to run as soon as the configuration data has been downloaded.

RTD Error

Module error on the 1756-IR6I module is defined in ohms and is calculated across

the entire input range that is selected, not the available range of a sensor used with the module.

For example, if the 1…487  input range is used, the module error is calculated across 507 (actual range = 0.86…507.86 ).

The error in ohms translates to temperature, but that translation varies because the

relationship is non-linear. The most effective way to check a 1756-IR6I module

error is to calculate the error in ohms and use that value in a linearization table to check the temperatureerror.

If the module is calibrated at operating temperature and the operating temperature remains relatively stable,

calibration accuracy is better than 0.1% of the full range for the first year after calibration.

This 0.1% value is a worst case value. In other words, with the 1…487input range that is selected,

the worst case module error is 0.507.
