Emerson 1.5m white Coax Extender Cable for DeltaV SIS KJ4010X1-BM3

Emerson has developed a DIN-rail mounted power supply incorporating four modular fanless powering systems

to provide reliable and stable power to the Ovation™ controller and I/O modules.

The Ovation controller powering system uses redundant configurations, each with separate, external wide-range AC and/or DC input feeds.

Dual diode auctioneered 24 VDC outputs are used to power each controller chassis and associated I/O modules, as well as loops and contact wetting to the I/O modules.

If required a 48 VDC auxiliary power for loops and contact wetting can also be provided.

Control Performance Monitoring

DeltaV InSight provides continuous control performance monitoring for every loop in your system, 24 hours a day,7 days a week.

Quickly assess control conditions across your entire system with overview displays that identify abnormal control conditions for the selected system,

area and module level. Once an abnormal condition is detected,

you may easily drill down to get detailed performance metrics and historical information on specific control blocks.

Two separate output schemes are available:

▪ 24 VDC / 10 A / 240 W main and 24 VDC / 10 A / 240 W auxiliary power

▪ 24 VDC / 20 A / 480 W main and 24 VDC / 20 A / 480 W auxiliary power

Benefits of the Ovation power supply scheme include:

▪ Separate main and auxiliary power supplies allow easy replacement

▪ Elimination of cooling fans greatly reduces failure risks

▪ Diode auctioneered power feeds assure continuous power availability

▪ New design increases efficiency, reduces heat generation and enhances equipment life expectancy

▪ Dual input (AC and DC) capability reduces spare parts

▪ Hot-swappable power supplies enable on-line replacement

▪ Quick installation of the power supplies minimizes downtime and production loss ▪ Power factor correction reduces power consumption

▪ Redundant power configurations, each with separate external wide-range AC or DC feeds

▪ Separate main and auxiliary supplies in both the primary and secondary configurations

▪ Dual wide-range input capabilities

▪ Diode auctioneered power feeds

▪ High-efficiency power supplies

▪ Modular fanless systems

▪ Redundant power feeds to each controller chassis and to the I/O modules

▪ Continuous system monitoring
