Ovation Controller Cabinets

Ovation controllers and I/O modules are all DIN rail

mountable, providing the flexibility to match controller

layouts with process requirements for various

locations, environments and space availability. The

normal configuration is to mount DIN rail items on

plates which can then be installed in existing or new

cabinet enclosures. Top and bottom entry for I/O

cables is available to meet required specifications.

A variety of controller and I/O cabinet configurations are available.

The basic controller cabinet houses a

chassis for single or redundant controllers and two I/O

branches on the front of the plate. Mounted on the rear

of the plate is a redundant power supply, power

distribution module and two additional I/O branches for

a total of 32 I/O modules since each I/O branch can

hold up to eight I/O modules.

Expansion cabinets house up to an additional 32 I/O

modules in four branches and a transition panel for

connection to the controllers. It can also provide

additional space for mounting redundant power

supplies (when required), and a power distribution module.

It utilizes high-performance microprocessors and integrated circuits that

It is characterized by high speed, reliability and stability, and is capable of real-time data acquisition and control.

At the same time, it also supports a variety of communication protocols to facilitate communication and integration with other devices.

The control/interface board is easy to use and program, and supports multiple

programming languages and development environments, making it convenient for users to carry out secondary development and customization.

This control/interface board uses high-performance microprocessors and integrated circuits that are high-speed, reliable, and stable.
