MOOG D137-001-011 Digital extension module

Moog engineers have achieved this by combining a highly efficient magnetic

circuit with energy rare earth magnets and an excellent thermal design.

Operation within a wide speed range provides excellent low speed tracking,

high dynamic speed tracking as well as high dynamic target acquisition.

Servo and Proportional Valves are part of the family of continuous valves.

Continuous valves are characterized by the fact that their output variable

(spool position, pressure, volume flow) is proportional to the input signal.

This is achieved by feedback of the spool position into a mechanical or electrical control loop.

Moog servo valves are characterized by the fact that the valve spool is inserted into a bushing (spool-in-bushing).

The servo valves are therefore characterized above all by outstanding dynamics and excellent accuracy.

Moog provides systems and component experience in developing and

supplying electric aiming and stabilization systems as well as drives for ammunition handling systems.

The Moog all-electric drives for turrets and weapons have demonstrated high

in service reliability for main battle tanks, infantry fighting vehicles,

howitzers and anti-aircraft applications around the world.

Moog’s brushless motors have been designed not only to meet and exceed

the demanding requirements of many combat vehicle electric control applications,

but to do so with more power per dimension.
