The CGM and CVM controllers can communicate using

BACnet MS/TP, N2. or wireless Zigbee. The controllers

auto-detect the protocol that is connected, which enables

the same controller to support multiple communication

protocols without the need to purchase a special model

per protocol, and without extra manual setup.

The XPM expansion modules can communicate using

BACnet MS/TP, or wireless Zigbee® using a ZFR/ZFR Pro

Wireless Field Bus Router (on the FC Bus only). By default,

the XPM expansion modules communicate using the

BACnet MS/TP protocol.

The BACnet MS/TP protocol is a standard for ANSI,

ASHRAE, and the International Standards Organization

(ISO) for building controls.

The CGM and CVM controllers can be used as functional

replacements for legacy N2 controllers. The N2-capable

MS/TP equipment controller models provide a cost

effective upgrade and modernization path for customers

with existing N2 controllers.

The CGM and CVM controllers can also be installed in a

wireless application using a ZFR/ZFR ProWireless Field Bus

Router, see Related products.

Hardware and installation

Metasys equipment controllers and expansion modules

are encased in a durable plastic housing. The plastic

housing may eliminate the need for a separate enclosure

for plenum-rated construction. Check specific controller

documentation and regional, national, and local code

requirements for appropriate applications.

Metasys CG, CV family devices feature bright, color-coded

LEDs, visible on the controller cover, that indicate the

supply power, communications bus, and EOL switch

status, as well as a variety of fault conditions to aid

troubleshooting the controller and bus.

The equipment controllers ship with a default state that

can assist in validating the wiring of the input and output

terminals prior to download of an application file. When

the controller is powered on in this state, the Fault LED

will flash in a pattern of two quick blinks and then a long

pause.
