Emerson PK22485002 Advanced Batch
❤ Add to collection

Emerson PK22485002 Advanced Batch

+86-18144100983
kongjiangauto@163.com
wind, petroleum, chemical, natural gas, Marine, mining, aviation, electronics, steel, nuclear power, electric power, coking, air separation and so on
PLC, DCS, servo, analog, Ethernet, digital, redundant module, tension system, excitation, generator management, human-machine interface, detection card, sensor, AC drive, etc
U.S.＄9898.00
U.S.＄3455.00
Weight：3.900KG
Quantity：
(Inventory: 3)
Buy now
Add to cart
Product parameters
  • Tell:+86-18144100983
  • email:kongjiangauto@163.com
  • Application:wind/ petroleum/ chemical/ natural gas/ Marine/ mining/ aviation/ electronics/ steel/ nuclear power/ electric power/ coking/ air separation and so on
  • Series:PLC/ DCS/ servo/ analog/ Ethernet/ digital/ redundant module/ tension system/ excitation/ generator management/ human-machine interface/ detection card/ sensor/ AC drive/ etc
Feature

Introduction

The Ethernet I/O Card (EIOC) provides a platform to access data  from Ethernet devices in the DeltaV™ system.

Ethernet Devices capable of talking Modbus TCP, EtherNet/IP, IEC 61850 MMS (Manufacturing Message Specification),

OPC UA client and EtherNet/IP Control Tag Integration protocols are supported.

The EIOC provides monitoring and control of Ethernet Devices on the Ethernet Device Network via control modules assigned

to and executed in the EIOC. Ethernet Devices like PLCs, Motor Control Centers, drives, switchgear and others can be

controlled directly by the EIOC, independent of a controller.

Benefits

Ability to communicate directly to Ethernet Device Networks.

Use the EIOC to monitor and control Ethernet Devices.

„ Powerful and Scalable. The EIOC allows a huge amount of data coming from Ethernet Devices to be accessed in DeltaV,

and is scalable to fit your needs with licensing based on thenumber of devices you connect.

The EIOC can bring:

z Up to 32,000 signals from 256 Ethernet Devices when using Modbus TCP, EtherNet/IP, or IEC61850 MMS.

z Up to 30,000 signals from 64 Ethernet Devices when using OPC UA client protocol.

z Up to 2000 tags (10 signals per tag) from 256 Ethernet

Devices when using EtherNet/IP Control Tag Integration Protocol.

Specifications

DST Limit 1500

SCADA Tags 3200

Max Data Values Sent 4000/second

Max Data Values Received 500/second

Max Unsolicited Client Nodes 120

Module Execution Rates 100ms, 200ms, 500ms, 1s, 2s, 5s, 10s, 30s, 60s

User Memory 96 MB

Fuse Protection (Internal) 3.0 A, non-replaceable fuses

Power Dissipation 5.0 W typical, 7.0 W maximum

Operating Temperature -40 to 60 °C (-40 to 140 °F)

Storage Temperature -40 to 85 °C (-40 to 185 °F)

Reltive Humidity 5 to 95% , non-condensing

Shock 10 g½-sine wave for 11 ms

Vibration 1mm Peak-to-Peak from 2 to 13.2 Hz, 0.7g from 13.2 to 150 Hz
