ABB PM510V08 3BSE00B373R1 32-bit RISC processor module



Single loop granularity - each SCM handles a single channel

Supports hot swap

Mechanical locking slider which turns off field device power and/or output before removal

Field disconnect function which can galvanically separate the field loop wiring from the SCM during

commissioning and maintenance

All SCMs have electronic current limitation

Mechanical keying to prevent insertion of wrong module type after commissioning

24V DC powered through Modulebus

Configurable through parameters

LED indicators on the SCM indicate the operational state of the module.

Real-time properties are implemented in the switch in order to

achieve determinism for real-time critical applications. NE810

supports QoS (Quality of Service) with four priority queues and

strict priority scheduling as well as HoL (Head of Line Blocking

Prevention). All to assure that the data network is deterministic.

Select I/O is an Ethernet networked, single-channel granular I/O

system for the ABB Ability™ System 800xA automation platform.

Select I/O helps decouple project tasks, minimizes the impact of

late changes, and supports standardization of I/O cabinetry

ensuring automation projects are delivered on time and under

budget.rnA Signal Conditioning Module (SCM) performs the

necessary signal conditioning and powering of the connected field

device for one I/O channel.
