Johnson Controls Simplex 4100-1254 2 Channel (full audio)

The CG and CV series equipment controllers are designed

to integrate seamlessly into the Metasys system by

connecting to, communicating with, and being supervised

by Metasys network engines (including SNE, SNC, NAE,

NIE, and NCE series network engines). This seamless

integration of equipment controllers with Metasys

network engines delivers coordinated, system-wide

control and enables building operators to monitor and

adjust equipment controllers from the Metasys system UI.

In addition, service personnel can view equipment

controller information locally through an optional local

controller display (MS-DIS1710-0) available for equipment

controllers, or through the optional Mobile Access Portal

(MAP) Gateway.

The CGM09090 and CGM04060 General Purpose

Application MS/TP Controllers (CGs) are equipment

controllers that run pre-engineered and user

programmable applications, and provide the inputs and

outputs required to monitor and control a wide variety of

HVAC and other facility equipment. CG series controllers

operate on an RS-485 BACnet® MS/TP Bus as BACnet

Advanced Application Controllers (B-AACs) and integrate

into Johnson Controls® and third-party BACnet systems.

CG series controllers include an integral real-time clock,

which enables the controllers to monitor and control

schedules, calendars, and trends, and operate for

extended periods as stand-alone controllers when offline

from the Facility Explorer® system network.

Communications protocols

The CGM and CVM controllers can communicate using

BACnet MS/TP, N2. or wireless Zigbee. The controllers

auto-detect the protocol that is connected, which enables

the same controller to support multiple communication

protocols without the need to purchase a special model

per protocol, and without extra manual setup.

The XPM expansion modules can communicate using

BACnet MS/TP, or wireless Zigbee® using a ZFR/ZFR Pro

Wireless Field Bus Router (on the FC Bus only). By default,

the XPM expansion modules communicate using the

BACnet MS/TP protocol.
