A-B 1783-BMS10CGL Stratix 5700 Ethernet Managed Switches

Universal Remote I/O (RIO) Network

The strength and versatility of the Universal Remote I/O network comes from the breadth of products it supports.

In addition to 1746 I/O, the Universal Remote I/O network supports many Allen-Bradley and third-party devices.

Typical applications range from simple I/O links with controllers and I/O, to links with a wide variety of other types of devices.

You connect devices through remote I/O adapter modules or built-in remote I/O adapters.

Using the Universal RIO Network instead of direct-wiring a device over a long distance to a local I/O chassis reduces installation,

tart-up, and maintenance costs by placing the I/O closer to the sensors and actuators.

SLC 5/03, 5/04, and 5/05 processors support pass-thru which lets you configure RIO devices remotely from an Ethernet,

DH+, or DH-485/DF1 network, as well as block transfer instructions for faster reading and writing of I/O data.

Common Industrial Protocol

(CIP) CIP™ is a messaging protocol for devices in industrial automation control systems.

CIP is the application layer for the EtherNet/IP network.

This protocol implements a relative path to send a message from the producing modules in a system to the consuming modules.

CIP uses the Producer/Consumer networking model instead of a source/ destination (Primary/Secondary) model.

The Producer/Consumer model reduces network traffic and increases speed of transmission.

In traditional I/O systems, controllers poll input modules to obtain their input status.

In the CIP system, digital input modules are not polled by a controller.
