ABB UAD149 Combi IO Module

Designed for total plant automation for a wide and varied set of process applications, the SD

Series features modular DIN rail packaging, a flexible, high-performance Fast Ethernet-based

plant network, and intelligent electrical and field device integration via PROFIBUS, HART,

IEC 61850. IEC 60870-5-104. DNP 3.0 and Modbus TCP communication protocols.

The SD Series also protects investments made in previous controllers, while delivering higher

performance, reliability and capacity.

From design conception through start-up and commissioning, the SD Series helps

reduce project deployment costs by:

• Minimizing DCS and extended support footprint

• Simplifying design complexity

• Compressing project schedules

Once in operation, the SD Series lowers total cost of ownership by:

• Increasing process reliability

• Minimizing equipment downtime

• Improving production yields

• Reducing maintenance and support costs

• Reusing physical and intellectual asset investments

• Enabling new products and functions to be added with ease

The IMSET01 Sequence of Events Timing module processes up to 16 digital field inputs, and

receives and decodes the time synchronization link information sent by the INTKM01 module for

a Harmony controller. The controller utilizes function code 241 (DSOE data interface) to interface

SOE data from the IMSET01 module to the INSEM01 module, and function code 242 (SOE digital

event interface) to configure and access the IMSET01 module input channels. Each channel is opti

cally isolated, and can be individually programmed for 24 VDC, 48 VDC, 125 VDC, and 120 VAC

input.

The module communicates with its Harmony controller over I/O expander bus. Only one

IMSET01 module can operate on an I/O expander bus segment. The module cable connects to

NTST01 and NTDI01 termination units. The NTST01 unit provides for time synchronization link

termination. The NTDI01 unit provides for field wiring termination.
