ABB SNAT602TAC Pulse Amplifier Module

ABB’s comprehensive service offering ensures life cycle support for medium voltage products

ranging from installation and commissioning, through condition monitoring and plant maintanace programs,

to decommissioning and recycling.

Our global network of service centers and experts help customers to optimize the performance of

their equipment without compromizing on reliablity and safetyDescription.

The IED also incorporates optional three-pole multi-shot auto-reclose functions for overhead line feeders.

Enhanced with optional hardware and software,the IED also features three light detection channels

for arc fault protection of the circuit breaker, busbar and cable compartment of metalenclosed indoor switchgear.

The arc-fault protection sensor interface is available on the optional communication module.

Fast tripping increases staff safety and security and limits material damage in an arc fault situation.

The IED offers directional and non-directional overcurrent and thermal overload protection as

well as directional and non-directional earth-fault protection.

Customer benefits and savings

• Risk Mitigation: Transfer of risk from client to ABB for coordinating design interface of all elements in the package to form a single product solution.

• Reduced Client Resources: ABB being responsible for the scope of works described above reduces client manpower to engineer and manage the project.

• Predictable Delivery & Cost Schedule: As a majority of the work is performed off site,

the client is insulated from local labor shortages, environmental & industrial relations factors, granting fewer and shorter isolation possessions.

• Reduced Site Resources: Comprehensive FAT can be performed before delivery reducing site commissioning requirements.

The data communication properties include the following communication standards: SPA bus, LON bus, IEC 60870-5-103.

IEC 61850 via SPA-ZC 400. Profibus DPV1 via SPA-ZC 302.

DNP 3.0 and Modbus communication with higher level equipment.

Further, the LON communication together with the PLC functions minimizes the need for hardwiring between the feeder terminals.
