ABB GDD360C Digital Input/Output Module

The process voltage supervision input give channel error signals if

the voltage disappears. The error signal can be read through the

ModuleBus. The outputs are current limited and protected against

over temperature. If the outputs are overloaded the output current

wi l be limited.

Features and benefits

• 16 channels for 24 V d.c. current sourcing outputs

• 2 isolated groups of 8 channels with process voltage supervision

• Output status indicators

• OSP sets outputs to predetermined state upon error detection

• Short-circuit protection to ground and 30 V

• Over-voltage and over-temperature protection

Fieldbus

MLink can include Fieldbus communication to DCS. The type of Fieldbus must be selected

before ordering the MLink type. The Fieldbus specific information (PROFIBUS, MODBUS etc.)

can be found in the following documents:

MNS iS Interface Manual Profibus

MNS iS Interface Manual Modbus

MNS iS Interface Manual Profinet IO

MService Condition Monitoring covers the following main functions:

 Collection of operational data of the supervised modules

 Collection of all alarms and trips generated in the supervised modules

 Collection of maintenance warnings derived from additional assessment logic related to the supervised modules.

 Display of the MNS or MNS iS system structure highlighting modules signaling problems

 Display of historical data in trend displays

 Detailed information on the identification, location, and type of supervised modules

 Online supervision of temperature or power loss related problems within individual cubicles.

MService can supervise all modules in MNS and MNS iS, which are connected to the internal

switchgear communication bus.
