DEIF CM-2 Deif Cm-2 Control Module

Compact size reduces space requirements

The AMC 600 is a compact controller that reduces space requirements in your control cabinets.

With a rack height of just 122 mm, it fits the de facto PLC standard, and the depth

is only 114 mm (130 mm with connectors). The I/O modules of the AMC 600 are

also high-density, reducing the required cabinet backplane footprint to 1.2 cm2 per digital I/O channel.

Fast, fail-safe, and secure system software

The AMC 600 uses a Linux OS maintained in-house by DEIF, a fast-starting, fail-safe,

robust, and secure system software. The architecture of the platform is fully open,

giving you full access to system set-up, plus a world of options including web-based configuration,

user management, IEC 61131-3 programming via CODESYS V3.5. and secure web-based visualisation.

A wide range of communication protocols like MODBUS RTU/TCP, OPC UA, CAN/CANopen, J1939.

and PROFINET are provided as standard. Controller redundancy is supported by the CODESYS

Controller Redundancy feature via Single Licenses.

The AMC 600 has two OS images that are separate from the application.

If a start-up or software update fails, the unit switches to the other image and completes the operation.

Both images can be updated, and troubleshooting can be carried out, using remote access.

The AMC 600 handles software updates itself.

Wide operating temperature range

The sturdy electronics design of the AMC 600 gives it a design lifetime of 10 years

at 40 °C ambient temperature, and the ability to operate from -40 to 70 °C. As a result,

you can use the AMC 600 all over the world. It can start from -40 °C and

can be stored from -40 to 85 °C. It will operate at a relative humidity

from 5 to 97% (condensing at 55 °C). This contributes to lower service costs,

and the long lifetime ensures high value for your investment and minimises electronic waste.
