The SLC 5/03, SLC 5/04, and SLC 5/05 processors have a serial port which is

configurable for RS-232 compatible serial communication. Use the serial port to connect

to devices that:

• communicate using DF1 protocol, such as modems, communication modules,

programming workstations, or other Encompass partner devices.

• communicate using DH-485 protocol.

• send and receive ASCII characters, such as ASCII terminals, bar code readers, and printers.

When configured for system mode, the serial port supports DF1 protocol. Use system

mode to communicate with other devices on the serial link.

The 1747-BSN features:

• backup of one Remote I/O or DH+ network per complementary BSN module pair.

• backup of one RS-232/DH-485 communications per complentary BSN module pair,

• allowing HMIs on channel 0 to automatically transfer to the primary processor.

• transfer of up to 2 K words of retentive data per BSN.

• repair of primary system fault during secondary backup system operation.

• remote programming capability of secondary processor on DH+ (SLC 5/04 only).

• minimal user program impact.

• backup system diagnostic information.

Ethernet Network

The TCP/IP Ethernet network is a local-area network designed for the high-speed exchange of information

between computers and related devices. With its high bandwidth (10 Mbps to 100 Mbps),

an Ethernet network allows many computers, controllers, and other devices to communicate over vast distances. An Ethernet network

The 1747-BSN module contains the full complement of RIO scanner features, plus

backup capability for support of redundant processor applications. The backup system

consists of one or more pairs of complementary modules, with one module residing in the

primary system and the other in the backup system. The primary system controls the

operation of remote I/O, while the backup system monitors communications via the

high-speed serial link (HSSL) and is available to take control in the event of a fault in the primary system.
