Emerson IC695EDM001 PACSystems RX3i DNP3 Ethernet Master

Product Description

FOUNDATION™ fieldbus I/O is a modular subsystem that communicates digitally with field devices,

increases your input/output capacity, and gives you access to more information about your process than conventional I/O subsystems.

It greatly enhances device diagnostics that affect your control strategy and alerts operators to device malfunctions.

If you want an efficient, economical, and secure process control system, use DeltaV™ FOUNDATION fieldbus I/O.

Ovation Simulation

Emerson offers Ovation Simulation solutions using virtual technology that faithfully replicates the

Ovation DCS within a simulator configuration by using a few desktop workstations.

This approach reduces hardware costs and footprint, allows easy portability for use throughout the facility,

and greatly simplifies ongoing simulator maintenance and upgrades to track ongoing control system modifications.

Ovation simulation is a valuable and flexible tool to improve plant operations.

Typical applications include DCS validation prior to its installation, operator training programs, engineering upgrades,and control changes to improve plant performance.

Maximize smart device capabilities. Increase your quality and throughput by taking advantage of the added diagnostics

of FOUNDATION Fieldbus I/O devices. Field device status is updated continuously using FOUNDATION Fieldbus I/O.

For multi-variable devices, all process variables are available on the single fieldbus at the cost of a single Device Signal Tag.

Redundant H1 cards provide increased availability.

The DeltaV system offers redundant H1 interfaces. The two H1

interfaces are connected with a redundant terminal block to

provide back-up link active schedule (LAS) capability that also

maintains communication with the host system.

Transfer to the standby card is automatic and requires no special configuration.

Ongoing diagnostics ensure the standby H1 card is available on demand.

This process requires no user interaction.

Leveraging Digital Intelligence

The Ovation PlantWeb digital plant architecture begins with a strong foundation of intelligent field devices from industry leaders such as Fisher and Rosemount.

With their digital capabilities — including onboard microprocessors, embedded software, and openstandard communications — these field devices can…

• Deliver precise measurement and control to reduce process variability.

• Handle multiple variables to reduce the number of devices required.

• Perform diagnostics to monitor device health, predict problems, and avoid downtime.
