Defining a 914-X Series System
914-X Series systems are used as linked pairs (one remote side and one console side) to provide a transparent
video, serial data, and Ethernet link over optical fiber(s). Cards are added as linked pairs; a card of the same type
is required at both the console and remote ends. The installed optical transceivers determine the maximum optical
link speed, fiber type, number of fibers (1 or 2), and link distance. The card version sets the operational bandwidth,
which is independent from the optical data rate. The optical link uses a proprietary data protocol which ensures
reliable transmission with extremely low latency using highly efficient and dynamic bandwidth utilization.
Typically, the uplink (remote to console) and downlink (console to remote) signals are combined on a single
fiber – multimode or singlemode (standard) – with a passive optical coupler known as a Wavelength Division
Multiplexer (WDM). The WDM is integrated in the optical transceiver. Standard, single fiber systems operate with
1310 nm uplink and 1550 nm downlink wavelengths. In larger systems, multiple 914-X Series stacks may be
combined on a single fiber using a Coarse Wavelength Division Multiplexer (CWDM) to take advantage of the high
bandwidth of optical fiber.
The Moog Focal Model 914-X Series Modular Multiplexer System is a compact and rugged transmission system
designed for industrial environments and other applications that require transmission of HD video, serial data, and
Ethernet over an optical link. The 914-X Series has been optimized for low power operation and delivery of low
latency, uncompressed video and Ethernet data.
A series of expansion cards are available, allowing additional composite video channels, serial data channels,
Ethernet ports, as well as many specialty signals such as TTL, hydrophone, CAN bus, and custom sonars to be
added to any 914-X Series system without requiring extra fibers or wavelengths.
