Honeywell 1309A0056 E3Point Monitor: Remote Sensor: Oxygen (O2)

Sensepoint XCD has an integral mounting plate for surface mounting or can be

mounted to a horizontal or vertical pipe using the optional pipe mounting bracket.

Electrical installation can be made using either conduit or cable with suitable

mechanical protection. Two M20 or ¾”NPT entries are provided (depending on

certification). A weatherproof cap is also included for use in the harshest outdoor

conditions. Other optional accessories include a sunshade/deluge protection, duct

mounting kit and collecting cone.

Flammable, toxic and Oxygen gas detector for industrial applications

The Sensepoint XCD range provides comprehensive monitoring of flammable,

toxic and Oxygen gas hazards in potentially explosive atmospheres, both

indoors and outdoors. Users can modify detector operation using the LCD and

magnet switches without ever needing to open the unit.

There are three different types of the XCD transmitter for use with three different

families of sensors.

The mV type transmitter is for use with the mV family of XCD sensors including

catalytic sensors to detect flammable gases in the range 0-100%LEL and infrared

(IR) sensors for detection of Hydrocarbon gases in the range 0-100%LEL.

Two IR Hydrocarbon sensors are available; one linearised to Methane and one

linearised to Propane. The Propane version has linear cross sensitivities factors for

Ethylene, Butane and Pentane. There is also an IR CO2 sensor available in the range

0-2%Vol.

The EC type transmitter is for use with the EC family of XCD sensors including

Carbon Monoxide (CO), Hydrogen Sulphide, (H2S), Nitrogen Dioxide (NO2)

and Hydrogen (H2).

The Oxygen transmitter is for use with the Oxygen (O2) XCD sensors.

A transmitter can auto-recognise any sensor from within its sensor family.

The sensor simply plugs into the bottom of the transmitter and the transmitter

automatically configures itself accordingly.
