Honeywell 1309A0039 Toxic and Combustible Gas Detector: H2 Cartridge: -40 to 50C: H2

The Intrinsically Safe smart sensors are supplied pre-configured and can be ‘hot swapped’ without

having to remove power to the detector, saving time and money during commissioning and routine

servicing. A remote sensor mounting kit is available that allows the sensor to be mounted up to

50’ (15m) from the transmitter, making it ideal for operation in areas that are difficult to access.

Series 3000 MkII is supplied with all necessary accessories for easy installation.

The detector can be mounted on a wall or support pole using the universal bracket provided.

Electrical installation can be made using either conduit or cable with suitable mechanical protection.

A ¾” NPT entry and M20 adapter are included as standard. A weatherproof cap is also included

for use in the harshest outdoor conditions.

2-wire loop powered toxic and oxygen gas detector for use in potentially explosive atmospheres

The Series 3000 MkII provides comprehensive monitoring of toxic and oxygen gas hazards

in potentially explosive atmospheres, both in and out of doors. This low powered gas detector

operates on an industry standard 2-wire 4-20mA loop, making it ideal for both new and retrofit

applications. Users can configure the detector without the need of a ‘hot work permit’ by using

the LCD and magnetic switches. Fault diagnostic software and configurable calibration intervals

simplify maintenance procedures.

The mV type transmitter is for use with the mV family of XCD sensors including

catalytic sensors to detect flammable gases in the range 0-100%LEL and infrared

(IR) sensors for detection of Hydrocarbon gases in the range 0-100%LEL.

Two IR Hydrocarbon sensors are available; one linearised to Methane and one

linearised to Propane. The Propane version has linear cross sensitivities factors for

Ethylene, Butane and Pentane. There is also an IR CO2 sensor available in the range

0-2%Vol.

The EC type transmitter is for use with the EC family of XCD sensors including

Carbon Monoxide (CO), Hydrogen Sulphide, (H2S), Nitrogen Dioxide (NO2)

and Hydrogen (H2).

The Oxygen transmitter is for use with the Oxygen (O2) XCD sensors.

A transmitter can auto-recognise any sensor from within its sensor family.

The sensor simply plugs into the bottom of the transmitter and the transmitter

automatically configures itself accordingly.
