Honeywell RM7800L1012 Burner Control with Display

Enjoy reduced labor and material costs when you go wireless with Honeywell TR20

wireless sensors. In both new and retrofit applications, the TR20 family integrates

seamlessly with a wide range of controllers, adding fully programmable building

automation control — without the hassles and costs of wires and conduits. Labor

time is greatly reduced, and sensor relocation is now a breeze. From vintage hotels

and historical buildings to modern office facilities, the point-to-point solution of TR20

wireless wall modules provides precision control that saves costs while preserving

the building’s appearance.

Honeywell’s Spyder™ Model 7 VAV controller is a programmable

room controller with integrated actuator and air flow sensor.

As a freely programmable VAV controller with universal inputs

and outputs, Spyder™ Model 7 has configuration flexibility to

achieve a variety of specific applications. Smart engineering and

commissioning tools with Niagara WEBs-N4 workbench and a

mobile application for test and balance make installation cost

effective.

Spyder™ Model 7 offers BACnet IP or BACnet MSTP, Sylk™ bus

technology, Modbus RTU RS-485. flexible universal input / output

(UIO) points and solid-state relays.

ALL-IN-ONE

• Freely programmable in WEBs-N4.

• Compact design for small enclosures and easy to install on round ducts.

• Color-coded, removable terminal blocks to simplify wiring

and replacement.

• Real-time clock, a supercapacitor for 24-hour data retention.

• 24 VAC power supply.

• 20 VDC at 75 mA auxiliary supply for field devices.

• Seven universal inputs/outputs usable as analog voltage/current

output or as a universal/binary input.

• All UI can be used for pulse input.

Maximum frequency 100 Hz, Minimum duty cycle (50 % / 50 %) 5

ms ON / 5 ms OFF.

• Five 24 VAC solid state relay outputs with 1.5 A continuous and 3.5

A in rush for 100 ms per SSR output.

• Features a non-isolated RS-485 interface for Modbus communication.
