DEIF PPU-2-GS-100033222.50 PROTECTION AND POWER MANAGEMENT SYSTEM

Flexible blackout prevention options

Designed for flexibility and efficient blackout prevention, the AGC 150 ATS includes an

Overlap feature that prevents blackouts during source switching by keeping the breakers

of both sources closed for a user-defined period and enabling short-time paralleling.

You can prioritise sources using parameters or digital inputs, offline or online, and you

can prioritise one of the connected sources, let the controller prioritise a source randomly,

or prioritise both in a three-breaker setup.

Two or three breakers supported

The AGC 150 ATS can control two or three breakers, allowing you to open and close a bus

tie breaker between the two power sources if needed. The controller can therefore be

configured for use in virtually any ATS application, anywhere in the world, including

the use of two sources simultaneously.

Easy setup and operation

You can easily configure the AGC 150 ATS for your application by adjusting its built-in

parameters or by using the M-Logic feature in DEIF’s free USW-3 utility software.

The sunlight readable LCD provides easy setup and quick access to important information.

On-screen text can be displayed in 8 languages, and the illuminated buttons smoothly

guide the operator and make the controller very easy and intuitive to operate.

Unmatched Performance and Flexibility

The iE 650 PLC Controller is designed to meet the demands of modern automation systems.

With its modular design, you can customize the controller to fit your specific needs.

Whether you need a standalone CPU module or a full PLC system with local and remote I/O,

the iE 650 PLC has you covered. Its high-density digital and analogue I/Os,

field bus communication, and condition monitoring capabilities make it the ideal choice for

various applications, including land, marine, and wind power control.

The iE 650 PLC is our high-end offering for tomorrow's intelligent energy solutions

requiring high reliability in demanding climatic conditions experienced on land,

marine or container-based turn-key solutions.

The iE 650 PLC is a PLC-based programmable automation controller (PAC) suitable for land,

marine, and wind power control applications. It is class approved and designed to

marine specifications and can withstand very harsh operating conditions.

Compact size reduces space requirements

The iE 650 PLC is a compact controller that reduces space requirements in your control cabinets.

With a rack height of just 122 mm, it fits the de facto PLC standard, and the depth is only

114 mm (130 mm with connectors). The I/O modules of the iE 650 PLC are also high-density,

reducing the required cabinet backplane footprint to 1.2 cm2 per digital I/O channel.
