LVCDJW00000750A Watlow (Temperature Limit Controller)

The LV / LF Series Temperature Limit Controllers are recommended for

any application where thermal system runaway could result in large

product scrap costs, damage to system equipment, potential fire hazard

or risk to personnel. Both controllers are Factory Mutual and CSA approved.

The LF and LV controllers are manufactured with or without an operator

interface and can be manufactured in square 1/8th DIN panel mount,

din rail mount, open board or potted module design configurations.

Push-on, quick connect spade terminal or removable screw clamp style

terminal block manufacturing options provide the electrical connections.

The Series LV includes an operator interface to allow viewing and selection

of the limit set point. A red four character, seven-segment LED displays the

limit set point. The limit set point selection is made with a continuous turn,

velocity-sensitive rotary encoder. Push-to-Set operation reduces accidental

limit set point adjustments. The Series LF offers fixed limit set points.

These units are manufactured without an operator interface.

The features and performance of the LF and LV controllers make them ideally

suited for a wide range of industrial limit control applications in the food

preparation, industrial machinery, packaging and plastic markets.

The F4T with INTUITION® temperature process controller

from Watlow® offers a wide range of field removable I/O

modules for maximum design flexibility. Configurations

can be custom tailored to meet the scaling needs of

a tremendous range of equipment and applications

while providing exactly the hardware types required for

compatibility. The F4T controller also features a 4.3 inch,

color, graphical touch panel. Combining power, flexibility and

functionality, this new controller offers unmatched versatility,

and its best-in-class ease of use could very well make user

manuals a thing of the past.
