GE IC800SSI228RD2-EE DeviceNet S2K Servo Controller

Field Control is a family of highly-modular distributed I/O and control products. They

are suitable for use in a wide range of host architectures.

The heart of the Field Control system is the Bus Interface Unit. The Bus Interface Unit

provides intelligent processing, I/O scanning, and feature configuration for a group of up to

eight I/O modules. Together, the Bus Interface Unit and its modules make up a Field Control

station.

The Bus Interface Unit and I/O modules are enclosed in sturdy, compact aluminum

housings. Bus Interface Unit and I/O modules bolt securely to separate Terminal Blocks,

which provide all field wiring terminals. The I/O Terminal blocks are generic and allow

different I/O module types to be mounted on the same base.  I/O Terminal Blocks are

available with box-type terminals, barrier-type terminals, or wire-to-board connectors.

All Terminal Blocks must be mounted on a DIN rail. The DIN rail, which serves as an

integral part of the grounding system, can also be mounted on a panel.

The individual module datasheets included in the Field Control I/O Modules User's

Manual, which provide specific module wiring information.

Conformance to Standards (GFK-1179). This manual describes the installation

requirements for programmable control products used in industrial environments,

specifically, in situations where compliance to standards or directives from the

Federal Communications Commission, the Canadian Department of

Communications, or the European Union is necessary. The information in this

manual is applicable for GE Fanuc Series 90-70 and Series 90-30 programmable

controller products, Genius I/O products,  and Field Control Distributed I/O and Control products.

Reduce the Engineering Effort and Cost

The use of Process Bus with the MU360 drastically reduces the

need for trenches, ducts, glands, cable trays and copper hardwiring,

as the information is exchanged among IEDs using fiber optic cables

and ethernet switches.

Fewer cables to manage also means reduced engineering complexity

as extensive wiring schematics are replaced by standardized

version-controlled configuration files. Future reconfigurations are

automatically documented by the IED configuration tool.
