Product Description P/N: IC300OCS200 Description / Specifications Description The IC300OCS200 is an Operator Control Station (OCS) that was originally created by GE Fanuc. Technical Specifications Brand General Electric Category HMI / MMI / OIT Part Number IC300OCS200 Subcategory Operator Interface Series Smart Stack Type Operator Control System Operating Temperature -10掳C to +60掳C Humidity 5% to 95% non-condensing NEMA Rating NEMA 4-12 Primary Power Range 10-30VDC Typical Power Draw 180mA @ 24VDC Inrush Current 270mA @ 24VDC for 1S User keys 32 Keypad 12 user-programmable keys + Shift, Esc, Enter, 4 direction keys and a full numeric keypad Display 4x20 LCD w/backlight ; 4.84w x 8.06h mm characters Information About IC300OCS200 The General Electric IC300OCS200, part of the Smart Stack series, is a highly reliable and efficient Operator Control System designed to meet the demanding requirements of various industrial environments. This system falls under the HMI/MMI/OIT category and serves as a critical component for effective operator interface management. With an operating temperature range of -10掳C to +60掳C and a humidity tolerance of 5% to 95% non-condensing, the IC300OCS200 is built to perform under a wide range of environmental conditions. Its NEMA 4-12 rating ensures protection against environmental factors such as dust and water, making it suitable for use in harsh industrial settings.

The primary power range for this system is 10-30VDC, with a typical power draw of 180mA at 24VDC. During startup, the system experiences an inrush current of 270mA at 24VDC for 1 second, ensuring quick and efficient power-up. These power specifications highlight the system's energy efficiency and suitability for various industrial power supply configurations. The IC300OCS200 features a user-friendly interface with 32 user keys, including 12 user-programmable keys, a Shift key, an Esc key, an Enter key, four direction keys, and a full numeric keypad. This comprehensive keypad layout allows operators to execute a wide range of commands and navigate the system efficiently, enhancing overall productivity. The display of the IC300OCS200 is a 4x20 LCD with backlight, providing clear and readable output even in low-light conditions. The display characters measure 4.84mm in width and 8.06mm in height, ensuring easy readability and reducing the risk of operator error. This makes the system suitable for applications where accurate data reading is critical. Designed for integration into various industrial control systems, the IC300OCS200 offers robust performance and reliability. Its construction and design meet the high standards required for industrial automation and control applications, making it an essential component in optimizing operational efficiency and ensuring seamless control processes. The General Electric IC300OCS200 Operator Control System is an advanced and versatile solution for operator interface management. Its comprehensive features, including a wide operating temperature range, humidity tolerance, NEMA 4-12 rating, energy-efficient power specifications, and user-friendly interface, make it a reliable choice for industrial environments. This system enhances operational efficiency by providing precise control and monitoring capabilities, ensuring that industrial processes run smoothly and effectively. The IC300OCS200 is ideal for use in a variety of applications, including manufacturing, process control, and automation systems. Its robust construction and reliable performance make it a valuable addition to any industrial control setup. By integrating this system into their operations, businesses can achieve improved productivity, reduced downtime, and enhanced overall efficiency. In conclusion, the General Electric IC300OCS200 Operator Control System is a high-performance, reliable, and user-friendly solution designed to meet the needs of modern industrial environments. Its advanced features and robust construction ensure that it can withstand the rigors of industrial use while providing precise and efficient control capabilities. Whether used in manufacturing, process control, or automation systems, the IC300OCS200 is a dependable choice for optimizing operational efficiency and ensuring the smooth execution of industrial processes. Manufacturer information General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions. IQElectro is not an authorized distributor. QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply.IQElectro sells SURPLUS onlyand DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
