WOODWARD BUM60-1224-54-B-001-VC-A0-0093-0013-G003-000 3522-1004 | Digital burner management and control module

Desciption

The 8273-140 is a digital speed regulator belonging to the Woodward brand.

It is widely used in the field of industrial automation, especially in systems that control complex production processes.

The 8273-140 digital governor has a variety of control modes,

which can be selected according to different application scenarios.

In addition, it also has overload protection function, which can prevent motor overload damage.

The 8273-140 digital governor also has remote control and monitoring functions,

and can communicate with the host computer through the communication interface.

In the field of industrial automation, 8273-140 digital governor is widely used in

speed control and position control of various motors,

which can improve production efficiency and product quality.

Module Description

The MicroNet expansion chassis may use either single or redundant power supplies. A motherboard

located on the back of the chassis allows the two power supplies to form a redundant power system

providing two separately regulated, 24 Vdc, 12 A outputs; two separately regulated, 5 Vdc, 20 A outputs;

and two separately regulated, 5 Vdc precharge outputs to the control. Power output regulation, including

line, load, and temperature effects, is less than ±5%.

POWER SUPPLY FAULT LED

—This red LED turns on when one of the supply’s three power converters

has shut down or one or more of the supply levels is below internally specified levels.

If this LED is on,check for a short circuit on external devices connected to the control’s power supply.

When redundant power supplies are running, current sharing circuitry balances the load to reduce heat

and improve the reliability of the power supplies.
