schneider 499NES18100 - Quantum modlue
❤ Add to collection

schneider 499NES18100 - Quantum modlue

+86-18144100983
kongjiangauto@163.com
wind, petroleum, chemical, natural gas, Marine, mining, aviation, electronics, steel, nuclear power, electric power, coking, air separation and so on
PLC, DCS, servo, analog, Ethernet, digital, redundant module, tension system, excitation, generator management, human-machine interface, detection card, sensor, AC drive, etc
U.S.＄8332.00
U.S.＄4102.00
Weight：3.000KG
Quantity：
(Inventory: 1)
Buy now
Add to cart
Product parameters
  • Tell:+86-18144100983
  • email:kongjiangauto@163.com
  • Application:wind/ petroleum/ chemical/ natural gas/ Marine/ mining/ aviation/ electronics/ steel/ nuclear power/ electric power/ coking/ air separation and so on
  • Series:PLC/ DCS/ servo/ analog/ Ethernet/ digital/ redundant module/ tension system/ excitation/ generator management/ human-machine interface/ detection card/ sensor/ AC drive/ etc
Feature

Discrete monobloc TBX modules (IP20) consist of either 16 discrete 24 V DC inputs, or 16 discrete

0.5 A transistor outputs, protected against overload and short-circuits, or 16 relay outputs. They

cannot be extended.

The Fipio connection point address assignment is set by 8 dip-switches (the 3 most significant dip

switches are not set), allowing up to 31 monobloc modules to be connected to the bus; Address 0

is reserved for the PLC (see Premium and Atrium Using EcoStruxure™ Control Expert, Fipio Bus,

Setup Manual). A display block indicates locally the status of the module and its inputs or outputs.

At a Glance

TBX monobloc modules have the following components:

 An element which groups together the communication electronics and the input and/or output

interfaces (1),

 a removable terminal block (2) enabling the sensors or preactuators to be connected directly to

the 16 discrete inputs/outputs of the module. The necessary power supplies are also wired to

the terminal block.

Sealed (IP65) Discrete Monobloc TBX Modules

General

Sealed (IP65) TBX monobloc Discrete modules comprise either 8 or 16 Discrete 24 VDC inputs,

or 8 or 16 Discrete 0.5 A static outputs, protected against overloads and short-circuits.

The Fipio connection point address assignment is set by 8 dip-switches, allowing up to 126

monobloc modules (IP65) to be connected to the bus (these dip-switches are located inside the

TSX BLP 10 connector). Addresses 0 and 63 are reserved. (see Premium and Atrium Using

EcoStruxure™ Control Expert, Fipio Bus, Setup Manual)

A display indicates locally the status of the module and its inputs or outputs.
