ABB 3BHE022294R0103 GFD233A103 LIN servo controller

INTKM01

The INTKM01 Time Keeper Master module provides time information to the INSEM01 module

and to the rest of the distributed SOE system through the time synchronization link. The

INTKM01 module connects to an external receiver using IRIG-B time code link. The module trans

mits absolute time to the rest of the system using the RS-485 time synchronization link.

The INTKM01 module cable connects to an NTST01 termination unit. In this case, the termination

unit provides the connection point for the external receiver signals and also the time

synchronization link.

IMSET01

The IMSET01 Sequence of Events Timing module processes up to 16 digital field inputs, and

receives and decodes the time synchronization link information sent by the INTKM01 module for

a Harmony controller. The controller utilizes function code 241 (DSOE data interface) to interface

SOE data from the IMSET01 module to the INSEM01 module, and function code 242 (SOE digital

event interface) to configure and access the IMSET01 module input channels. Each channel is opti

cally isolated, and can be individually programmed for 24 VDC, 48 VDC, 125 VDC, and 120 VAC

input.

The module communicates with its Harmony controller over I/O expander bus. Only one

IMSET01 module can operate on an I/O expander bus segment. The module cable connects to

NTST01 and NTDI01 termination units. The NTST01 unit provides for time synchronization link

termination. The NTDI01 unit provides for field wiring termination.
