Selecting a ControlLogix System

The ControlLogix system architecture provides sequential, process, and

motion control together with communications and state-of-the-art I/O in a

small, cost-competitive package. The system is modular, so you can design,

build, and modify it efficiently - with significant savings in training and engineering.

A ControlLogix system can be anything from a simple chassis to a highly-distributed

system consisting of multiple chassis and networks working together.

A simple ControlLogix system consists of a stand-alone controller and I/O modules in a single chassis.

Or you can use the ControlLogix system as a gateway.

Include the communication modules you need for connectivity to other networks.

For this use, a controller is not required. The ControlLogix Gateway integrates

into existing PLC-based systems so that users with existing networks can

send or receive messages to or from other networks.

For a more robust system, use:

• multiple controllers in a single chassis

• multiple controllers joined across networks

• I/O in multiple platforms that is distributed in many locations and connected over multiple I/O links
