A-B 1585D-M4DC-SH M12 D-code IDC connector compatible with 600V cable spools

GuardLogix 5580 Safety Controllers

• Achieves SIL CL 2 / PLd with primary controller

• Achieves SIL CL 3 / PLE with primary controller plus safety partner

• Optimized for faster safety reaction time to achieving protective device coverage and reducing the risk of injury

• Offers Standard memory options from 3...20 MB

• Offers safety memory options from 1.5...6 MB

• Offers communication options from 100...250 EtherNet/IP nodes

• Offers conformal coated options for harsh environments

• Provides single controller/software/network for standard and safety control

• Includes mix and match safety and standard I/O

• Provides networked safety functions with motion and the following drives: Kinetix® 5700 with Advanced Safety and PowerFlex® 755 with Advanced Safety

The 1747-BSN features:

• backup of one Remote I/O or DH+ network per complementary BSN module pair.

• backup of one RS-232/DH-485 communications per complentary BSN module pair,

• allowing HMIs on channel 0 to automatically transfer to the primary processor.

• transfer of up to 2 K words of retentive data per BSN.

• repair of primary system fault during secondary backup system operation.

• remote programming capability of secondary processor on DH+ (SLC 5/04 only).

• minimal user program impact.

• backup system diagnostic information.

Selecting a ControlLogix System

The ControlLogix system architecture provides sequential, process, and

motion control together with communications and state-of-the-art I/O in a

small, cost-competitive package. The system is modular, so you can design,

build, and modify it efficiently - with significant savings in training and engineering.

A ControlLogix system can be anything from a simple chassis to a highly-distributed

system consisting of multiple chassis and networks working together.

A simple ControlLogix system consists of a stand-alone controller and I/O modules in a single chassis.

Or you can use the ControlLogix system as a gateway. Include the

communication modules you need for connectivity to other networks. For

this use, a controller is not required. The ControlLogix Gateway integrates

into existing PLC-based systems so that users with existing networks can

send or receive messages to or from other networks.

For a more robust system, use:

• multiple controllers in a single chassis

• multiple controllers joined across networks

• I/O in multiple platforms that is distributed in many locations and

connected over multiple I/O links
