Watlow 0600-0094-0000 F4T Controller Quick Start Guide

The end user, the machine builder or the system integrator expects the

best solutions in terms of performance, ease of use and reliability in

order to control the energy delivered to their process.

Whether replacing an existing product or building a new process, the

EPack Lite SCR (Silicon Controlled Rectifier) power controller has been

carefully designed to aid easy and fast integration in industrial systems.

The EPack Lite controller range offers a simplified choice, fast commissioning

without any compromise on performance in order to provide a high level of

quality, accuracy and reliability to the process.

More than just a product, EPack Lite power controllers bring a tailored solution

based on more than 50 years of Eurotherm expertise.

Watlow’s F4T with INTUITION® Combines the Flexibility of a

Modular I/O Controller with Best-in-Class Ease of Use

The F4T with INTUITION® temperature process controller

from Watlow® offers a wide range of field removable I/O

modules for maximum design flexibility. Configurations

can be custom tailored to meet the scaling needs of

a tremendous range of equipment and applications

while providing exactly the hardware types required for

compatibility. The F4T controller also features a 4.3 inch,

color, graphical touch panel. Combining power, flexibility and

functionality, this new controller offers unmatched versatility,

and its best-in-class ease of use could very well make user

manuals a thing of the past.

The MLS300 series controllers provide 16 or 32 fully

independent loops of PID control. When used as a stand-alone

controller, you may operate the MLS300 via the two-line 16-

character display and touch keypad. You can also use it as the

key element in a computer-supervised data acquisition and

control system; the MLS300 can be locally or remotely

controlled via an EIA/RS-232 or EIA/RS-485 serial

communications interface.

Watlow 0830-0870-0000 Protective screen cover (2 per pack)

Watlow 0822-0705-0000 F4T 1/4 DIN mounting collar - thru front panel mount

Watlow 0216-1285-0000 Flush mount - mounting adapter plate

Watlow 0847-0400-0000 USB 2.0 to RJ45 Ethernet adapter

Watlow 0238-1245-ALUM Accent bar (brushed aluminum gray)

Watlow 0238-1245-REDD Accent bar (brushed aluminum red)

Watlow 0238-1245-BLUE Accent bar (brushed aluminum blue)

Watlow 16-0246 Current transformer

Watlow 0804-0147-0000 RC supression - Quencharc®

Watlow 0601-0001-0000 Controller support tools (DVD)

Watlow 0830-0808-0001 (CAPUSB-MB5) Rubber plug USB mini

Watlow 0830-0808-0002 (CAPUSB-A) Rubber plug USB host

Watlow 0830-0858-0000 Replacement battery

Watlow 0822-0769-0000 Module slot plug (for vacant F4T slots without flex modules

Watlow 0600-0092-0000 Installation and Troubleshooting User Guide
