HIMA X-AI 32 01 Analog Input Module



The X-CPU 01 processor module is an absolute necessity for data

processing within the HIMax system.

Data processing within the HIMax system is absolutely essential.

The processor module is used to:

Process up to 32 user programmes

Perform all central functions including communication

Handle the redundant functions of up to 3 additional processor modules

Communicate via secure Ethernet

Create and store CPU events.

Stores events created by the I/O modules.

The module is TÜV-certified for safety-related applications up to SIL 3.

(IEC 61508. IEC 61511 and IEC 62061), Cat. 4 (EN 954-1) and PL e (EN ISO 13849-1).

Safety features of the module

The safety features of the processor module include the following:

Handling of the user programme

- If a fault occurs Stop the user programme and reset the variables to their initial values.

- If a fault occurs: Reset the processor module to a safe state and report the CPU status

Safe communication between the HIMA controllers (HIMax, HIMatrix and remote I/O modules)

using the safety-related safeethernet protocol.

Data transfer can be carried out using the Ethernet interface of the processor module itself, or

The data can be transferred using the Ethernet interface of the processor module itself

or using the Ethernet interface of the COM module.

The safety function complies with the SIL 3 standard

HIMA products provide you with maximum long-term equipment availability.

For this reason, we are constantly updating our product portfolio with new technologies.

Compatible successor products ensure that your security system will

continue to operate smoothly for many years after installation.

This reduces life cycle costs, avoids unplanned downtime and ensures

that your assets are protected by your investment.

The HIQuad H41q/H51q was introduced to the market in 1997 as the third

generation of central modules.

In 2018. a fourth-generation central module was introduced to ensure

the sustainability of the HIQuad system family.

HIMA X-DI3201 985210201 Digital input module

HIMA X-DO2401 985210203 Digital Output Module

HIMA 80105 984080105 versatile communication module

HIMA F3DIO20/802 982200442 Digital Input Module

HIMA Z7116/3236/C5 Connection Module

HIMATRIX F3001020 | HIMA Safety-Related Controller
