AKD-P00306-NBEC-0000 Kollmorgen Servo Drive

The analog input terminals process signals in the range between

and 20 mA. The currentis digitised to a resolution of 12 bits andis

transmitted, in an electrically isolated form, to the higher-level

automation device. In the 4-channel Bus Terminal, the four inputsare

2-wire versions and have a common ground potential. The reference

ground of the inputs is the internal ground. The 8-channelvariant

combines all eight channels in one housing and is particularly suitable

for space-saving installation in control cabinets. Theuse of single

conductor connection technology enables the connection of

multi-channel sensor technolgy with minimum spacerequirements.

The reference ground for allinputs is the OV power contact. In both

Bus Terminals the power contacts are connectedthrough. Overload

is detected in both variants. The terminal status is relayed to the

controller via the standard-bus. The LEDs indicatethe data exchange

with the Bus Coupler as well as overload or wire breakage.

Modified Standard

Because our application expertise runs deep and our

product portfolio is so broad, we can take any standard

product and modify to different degrees to suit your

specific needs – without significant sacrifice of lead time

or cost. This approach ensures quality, performance

and reliability by leveraging our proven track record.

Kollmorgen application engineers have a great deal

of experience helping OEM engineers achieve their

objectives. Typical motor modifications include: shaft,

housing, winding, feedback type, mounting and connectors.

Engineering Excellence

What really sets us apart is our engineering expertise.

With over 50 years of successfully designing custom

motors, we are able to quickly assess, design and

implement a solution that meets your needs.

Our engineering team has decades of experience

in motor design, which means they have designed

solutions for almost every unique and challenging

situation. Their insightfulness and expertise will guide

you through the development and implementation of

an optimized motor solution.

We rely on the most advanced simulation tools to

deliver the best products, designed to withstand the

most unique and challenging environments.
