TBX modules

TBX distributed input/output modules provide the following:

 a high level of adaptability: they may be mounted in any position, on any type of support

(mounting plate, frame, DIN rail for TBX IP20s, etc.), in all industrial environments,

 the interface elements take up less space,

 easy to set up and connect: sensors and preactuators are directly connected to screw terminals

(eliminating the need for intermediate terminal blocks), integral commons, several marking

levels (operational, electrical, for identifying modules and connection points, etc.),

 connection close to the sensors and preactuators in a harsh environment using TBX IP65.

 A high level of modularity in order to adapt to the number and type of sensors and preactuators

in a cell: input modules, output modules, mixed input/output modules and modules with

programmable channels,

 local management of operating modes and diagnostics, of connection points and connected

channels,

 conformity with international standards.

Distributed inputs/outputs

The decentralization of inputs/outputs enables the requirements of both users and machine

manufacturers to be met while obtaining performance comparable with that of a centralized

architecture:

 the volume of wiring connected to sensors and preactuators is reduced,

 mechanical constraints associated with wiring ducts are eliminated,

 time required for designing and testing connections is reduced,

 machine or plant availability is maximized,

 installations are more flexible and open to expansion,

 PLCs can be operated more rationally.
