Discrete monobloc TBX modules (IP20) consist of either 16 discrete 24 V DC inputs, or 16 discrete

0.5 A transistor outputs, protected against overload and short-circuits, or 16 relay outputs. They

cannot be extended.

The Fipio connection point address assignment is set by 8 dip-switches (the 3 most significant dip

switches are not set), allowing up to 31 monobloc modules to be connected to the bus; Address 0

is reserved for the PLC (see Premium and Atrium Using EcoStruxure™ Control Expert, Fipio Bus,

Setup Manual). A display block indicates locally the status of the module and its inputs or outputs.

At a Glance

TBX monobloc modules have the following components:

 An element which groups together the communication electronics and the input and/or output

interfaces (1),

 a removable terminal block (2) enabling the sensors or preactuators to be connected directly to

the 16 discrete inputs/outputs of the module. The necessary power supplies are also wired to

the terminal block.

Sealed (IP65) Discrete Monobloc TBX Modules

General

Sealed (IP65) TBX monobloc Discrete modules comprise either 8 or 16 Discrete 24 VDC inputs,

or 8 or 16 Discrete 0.5 A static outputs, protected against overloads and short-circuits.

The Fipio connection point address assignment is set by 8 dip-switches, allowing up to 126

monobloc modules (IP65) to be connected to the bus (these dip-switches are located inside the

TSX BLP 10 connector). Addresses 0 and 63 are reserved. (see Premium and Atrium Using

EcoStruxure™ Control Expert, Fipio Bus, Setup Manual)

A display indicates locally the status of the module and its inputs or outputs.
