Product overview

SYMAP® is a flexible microprocessor-based digital protection device for use in low, medium and

high voltage power systems.

Because of its integrated protection functions and human machine interface capabilities it is an

efficient and cost-effective solution for all types of switchboards. With three powerful microproces

sors SYMAP® offers comprehensive protection functions for generators, motors (synchronous and

asynchronous), transformers, power lines and distributions.

SYMAP® is easy to program and operate. A large graphic LCD with optional LED indicators conveys

important data such as position of all connected breakers, parameter settings, and event histories

at a glance. Graphics and measurements are displayed side-by-side on the LCD, so that the user does

not have to switch between pages.

The entire programming of SYMAP® can be

done with the keys on its front panel or by

using a notebook. Using a notebook offers

the advantage that stored parameters can

easily be applied to other SYMAP® units.

Either way, easy programming is guaranteed

and on-site visits by the manufacturer’s engi

neers during commissioning is not required.

SYMAP® provides four hotkeys placed under

neath the LCD to access four main groups of

values, namely »Meters«, »Alarm«, »Process«

and »Breaker Control«. The user can press the

hotkeys to scroll through pages of information.
