Emerson IC220MDL644 Input 24 VDC Positive Logic 16 Points

Access to DeltaV Live graphics, DeltaV Operate graphics, and

the alarms and history collection from EIOC control modules

follows the same rules and mechanisms as control modules

running in the controllers in a DeltaV System.

The EIOC mounts on the dual horizontal carrier, which includes

redundant Power input Terminals as well as redundant

Ethernet Isolation ports. The Ethernet Isolation ports isolate

the redundant DeltaV Control Network communication

from the redundant Ethernet Device Networks. An Industrial

Networks Firewall is recommended to provide added security

based on deep packet inspection to restrict communications

at the Ethernet device and Ethernet protocol level. In this way,

Robustness and Security is ensured.

Control Execution

Like the Ovation OCR1100 controller, the OCR3000 performs complex modulation,

discrete and sequential control strategies, as well as data acquisition and monitoring functions.

The OCR3000 controller can generate up to 64,000 points.

With a quad-core processor, the OCR3000 controller supports up to five control tasks with loop speeds ranging from 10 milliseconds to 300 seconds.

Each control task consists of an I/O flow point input scan, a control scheme execution, and an output scan.

The loop speed for all five control tasks is user selectable.

Each of the five control tasks can range from 10 milliseconds to 300 seconds.
