Emerson IC695CMX128 RX3i Control Memory Xchange Module

Specifications

• Number of segments (ports)

• 2

• Number of field devices

• 16 per port (dependent on device power consumption)

• Number of Ff funtion blocks

• 96 per card (64 fieldbus and 32 standard DeltaV)

• Voltage provided per segment

• 28-30 VDC (short circuit protected)

• Current provided per segment

• 400 mA (short circuit protected)

• Isolation

• Each port is isolated from the system and from each other and factory tested to 1500 VDC.

• Nominal signal range (span)

• Fieldbus Foundation IEC 61158-2

• LocalBus current per card (12 VDC nominal)

• 200 mA typical, 300 mA maximum

• Heat Dissipation

• 7.2 W

• Operating Temperature

• -40 to 70 °C (-40 to 158 °F)

• Storage Temperature

• -40 to 85 °C (-40 to 185 °F)

• Reltive Humidity

• 5 to 95% , non-condensing

• Shock

• 10 g½-sine wave for 11 ms

• Vibration

• 1 mm peak-to-peak from 5 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz

Features

• Increase I/O capacity while reducing wiring

• Reduces Footprint due to 4-ports

• Maximize smart device capabilities

• Redundant H1 cards provide increased availability

• Provides synchronized control

Company Portfolio

Industry leaders are looking to Emerson as a trusted partner that continuously innovates to help them meet the next big challenge.

Our robust automation portfolio enables us to collaborate across our businesses to develop more complete solutions

for customers based on our deep industry experience.

We leverage our global presence, domain expertise and industrial software to help industries achieve key sustainability and operational goals.

Maximize smart device capabilities. Increase your quality and throughput by taking advantage of the added diagnostics

of FOUNDATION Fieldbus I/O devices. Field device status is updated continuously using FOUNDATION Fieldbus I/O.

For multi-variable devices, all process variables are available on the single fieldbus at the cost of a single Device Signal Tag.

Redundant H1 cards provide increased availability.
