DS200TCEBG1BAA | General Electric Protective Termination Expander Board Mark V

Product Description P/N: DS200TCEBG1BAA DESCRIPTION / SPECIFICATIONS Description The DS200TCEBG1BAA is a General Electric Protective Termination Expander Board for the Mark V turbine control system. This board provides additional termination points for protective relays, allowing for expanded system connectivity and enhancing overall reliability. It ensures precise signal routing and integration within the control system, supporting critical safety functions and maintaining the integrity of the turbine operation. The DS200TCEBG1BAA is essential for expanding the protective capabilities of the Mark V system. Technical Specifications Condition New / Never Used Surplus Brand General Electric Category PLCs/Machine Control Part Number DS200TCEBG1BAA Subcategory PC Board PLC/Add-On Board Series Mark V Product Type Common Circuits EOS Board Functional Acronym TCEB PCB Coating Normal Coating Functional Revision 1 B Functional Revision 2 A Artwork Revision A Power Requirements +5 V dc, 6 A Core Slot P1 TCEB Connectors JMP, JU, JV, JVA, JWX, JPU, JPV Operating temperature -30 to +65掳C Size 15.9 cm high x 17.8 cm Information About DS200TCEBG1BAA The DS200TCEBG1BAA is a Protective Termination Expander Board developed by General Electric as part of its renowned Mark V series, a key component in the management and protection of complex industrial control systems. This board plays a critical role in extending the capabilities of a PLC (Programmable Logic Controller) setup, specifically designed to handle common circuits within the Mark V architecture.

Engineered for high-reliability environments, the DS200TCEBG1BAA is integral in ensuring the efficient operation and protection of industrial processes. As a protective termination expander board, the DS200TCEBG1BAA is designed to interface with other components in the control system, providing additional termination points that enhance the flexibility and scalability of the Mark V system. This functionality is essential in applications where multiple inputs and outputs must be managed, ensuring that the control system can be expanded without compromising on performance or reliability. The DS200TCEBG1BAA features a variety of connectors, including JMP, JU, JV, JVA, JWX, JPU, and JPV, which facilitate the integration of the board with other components in the system. These connectors are strategically designed to ensure secure and reliable connections, minimizing the risk of signal loss or interference, which is crucial in maintaining the integrity of the control processes. The presence of multiple connectors also underscores the board's role as an expander, allowing it to support additional circuits and enhancing the overall functionality of the Mark V control system. This board is equipped with a normal PCB coating, providing a basic level of protection against environmental factors such as dust and moisture. While not as robust as conformal coatings, this standard coating is sufficient for many industrial environments, ensuring that the board remains operational under typical operating conditions. The DS200TCEBG1BAA is designed with durability in mind, capable of withstanding operating temperatures ranging from -30掳C to +65掳C, which makes it suitable for a wide range of industrial applications where temperature fluctuations are common. In terms of power requirements, the DS200TCEBG1BAA operates on a +5 V dc supply, drawing a current of 6 A. This power specification is typical for boards of this type within the Mark V series, ensuring compatibility with the overall power architecture of the control system. The board's power requirements are carefully calibrated to balance performance with energy efficiency, ensuring that it delivers reliable operation without excessive power consumption. The DS200TCEBG1BAA is part of the EOS (End of Service) Common Circuits category, which indicates its role in managing the end-of-service signals within the control system. This functionality is critical in ensuring that the system can safely and efficiently handle shutdowns or transitions to a standby mode, preventing damage to equipment and minimizing downtime. The board's ability to manage these signals effectively makes it an essential component in maintaining the safety and reliability of the control system. The board's design includes a core slot labeled P1TCEB, which is a designated interface for connecting the board to the central processing unit or other core components of the Mark V system. This slot ensures that the board can communicate effectively with the rest of the system, facilitating the flow of data and control signals necessary for the proper operation of the entire setup. The P1TCEB core slot is a key feature that enhances the board's integration capabilities, making it a versatile addition to the Mark V series. The DS200TCEBG1BAA has undergone multiple revisions, with functional revisions 1B and 2A indicating improvements and updates to its design and performance. These revisions reflect General Electric's commitment to continuous improvement, ensuring that the board remains at the forefront of technological advancements in industrial control systems. The artwork revision labeled "A" further underscores the attention to detail in the board's design, ensuring that it meets the high standards required for use in critical industrial applications. Manufacturer information General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions. IQElectro is not an authorized distributor. QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply.IQElectro sells SURPLUS onlyand DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
