Honeywell 900RTC-L150 Low Votage RTP Cable (5.0M 16.4ft.)

EXPERION HS

Experion HS is a powerful software platform that incorporates innovative

applications for human machine interface (HMI) applications and supervisory control and data acquisition (SCADA).

Built upon the proven technologies of the Experion platform,Experion HS is an integrated and affordable solution for smaller unit

operations. Experion HS enables seamless integration, configuration and data exchange with the ControlEdge HC900 system.

When paired with Experion HS, ControlEdge HC900 can meet FDA 21 CFR part 11 requirements for pharmaceuticals,

food and beverage industry that need a proven and reliable solution capable of advanced controller security and protection methods,

change management and automated electronic record keeping.

ControlEdge HC900 also has pharma specific function blocks which significantly simplify your engineering efforts.

CONTROLEDGE HC900 ALLOWS YOU TO PERFORM EASY ENGINEERING

• HC Designer Configuration Software available in English and Chinese Mandarin

• Process-specific function blocks reduce configuration time and your operational costs

• Powerful Accutune III auto-tuning algorithms enable control loops to be quickly and easily tuned

• Simple intuitive tools, advanced monitoring and debugging tools which are easy to use and engineer

• Product enhancements made easy with web-based downloads at zero annual maintenance fee

Failsafe

All ControlEdge 900 Platform I/O modules support a user

specified failsafe value (analog) or state (digital) that the

module outputs or inputs will assume if communication

between the controller and the module is interrupted. Output

modules are also disabled if the controller fails to start.

Module diagnostics are not initiated if the control strategy

does not call for the inputs or outputs on the modules to execute.

Failsafe is restricted to de-energize in safety applications.

ControlEdge™ is a next generation family of controllers providing secure connectivity

through all levels of process and business functions, optimized operations,

and maintenance efficiencies to meet your diverse automation needs.

These controllers additionally support inherent integration with Experion® systems when needed to deliver a fully cohesive automation solution.

The ControlEdge family of controllers turns data into actionable insight, from edge to enterprise, to help customers improve their bottom line.

Insert and Removal of I/O under Power

For ease of maintenance, the ControlEdge HC900 controller

supports removing and inserting I/O modules from the

module rack without removing power from the controller.

Each module is sensed for validity by the controller

and auto-configured on insertion.

Other Modules

In addition to I/O, the following modules are available.

 Scanner 1 module, single port (p.31)

 Scanner 2 Module, dual port (p.32)

 Universal AC Power Supply, 60W (p.4)

 Power Supply 24VDC, 60W (p.4)

 Redundant Switch Module (p.33)

 Power Status Module (p.33)
