Vibro-meter vmf-MPC4 200-510-111-034 200-510-070-113 Module

Other critical rotating machinery

Therefore, whilst Mechanical Protection and Condition Monitoring cards can easily share sensor

signals from the measurement chain, in a VM600 rack, the MPC4/IOC4T card pair

does not share any communication buses with the XMx16/XIO16T Condition Monitoring card pair

and the MPC4/IOC4T card pair is configured and operated using the VM600 MPSx

software (whereas the XMx16/XIO16T card pair is configured and operated using the VM600 MPSx software).

XIO16T card pair is configured and operated using VibroSight® software).

The Vibrometer VM600Mk2 is designed to provide state-of-the-art vibration monitoring and protection (SIL 2),

especially for large critical rotating machinery with high channel counts.

Its modular 19-inch card allows the user to build a system to suit specific application requirements.

In addition, the system can be integrated with VibroSight software, which provides detailed insight into the

condition of rotating machinery and a wide range of analysis options.

Applications

The VM600Mk2 is suitable for plants where rotating machinery is concentrated in one area,

requiring centralized monitoring and a high channel count.

Typical applications include:

■ Gas turbines

■ Steam turbines

■ Water turbines

The “Standard” MPC4 card is the original version and supports all functions and processing modes.

card pairs and the RLC16 relay card. It has a VME-compatible slave interface so that it

can be configured via software via VME when VME is available.

It is software configurable via VME when acting as a rack controller in a VM600 rack.

It is also software configurable via RS-232 (on the front panel of the card).

The 'Secure' (SIL) MPC4 card (MPC4SIL) has been developed to provide a wider range of installation options.

Specifically, the VM600 rack also contains condition monitoring cards (e.g. XMx16) and relay cards (e.g. IRC4).

In order to certify the security of these configurations, it is necessary to ensure that the MPC4SIL

is isolated from the other cards in the VM600 chassis so that its configuration is not inadvertently modified.
