H&B Contronic XU 13 Module XU 13 H&B Contronic

H&B Contronic XU 13 Module Manufacturers ABB, Hartmann & Braun Model(s)

ABB H&B Contronic Additional Information H&B Contronic XX02 Module

Estimated Shipping Size Dimensions: 5.0" x 1.0" x 8.0" (12.7 cm x 2.5 cm x 20.3 cm)

Weight: 0 lbs 4.0 oz (0.1kg ) XU 13

With ARC600. conventional IEC 60870-101 serial devices can

be attached to a modern TCP/IP based IEC 60870-5-104

control system. This is enabled by the protocol conversion

from IEC 60870-5-101 to IEC 60870-104. In this case,

ARC600 (IEC-101 master) uses local synchronous data

polling where it continuously sends requests and the IEC-101

device (IEC-101 slave) responds. In the direction of the

control room, the communication protocol is IEC-104 and

ARC600 can send events asynchronously as they arise while

SCADA performs only slow-period background scans.

Another advantage of the local protocol conversion is an

advanced data acknowledgement mechanism. IEC-104

allows multiple packets, and multiple events in a single

packet, to be acknowledged collectively and the packets can

be buffered up to the time of acknowledgement from SCADA.

• Fault passage indication

• Additional push buttons for local control

• Microswitch for door alarm (standard feature for GAO)

• Fixing accessories for mounting on top of

switchgear or floor mounting (GAI)

• Auxiliary contacts for micro circuit breakers (MCB)s

• Fused supply socket

• Control circuit 48 VDC

• Service light

• Fused 12 VDC supply for additional radio equipment

• Different antenna options depending tocustomer specification

• Surge protection T1+T2

• Low auxiliary voltage indicator

• Low-voltage measurements (GAI)

• Communication with MV/LV measurement equipment (GAI)

• Connection interface for additional motor

operating cabinets (GAO)

• Different battery management options for

monitoring the battery health wireless networks
