HIMA X-A0 16 01 16 channels 4 .. 20 mA Analog output module



HIMax adapts to all I/O-count, response-time and fault-tolerance requirements as well

as centralized and distributed applications. HIMax delivers availability for life by enabling

uninterrupted system operation throughout your plant’s life cycle. Hardware and software

changes can be performed without system interruption. Alternative CPU modules make

HIMax suitable for meeting high performance and critical control requirements as well

as for use in small and mid-sized safety applications.

Plug-ins for SILworX

• Independent modules that run in their own processes

• Start automatically with SILworX or manually by the user

• Access to SILworX via the SILworX API function

In large projects several people work together on one project and need to manage different

versions or parts of the same project.

SILworX Multi-File-Project streamlines both versioning activities and team collaboration.

This enhances the digital work process which generates more efficiency and saves more time.

SILworX allows you to program and configure your HIMA safety-related controllers

and diagnose errors in an intuitive user interface. This results in fewer user errors

and faster engineering – enabling you to commission your safety system more quickly

and adapt it to new requirements immediately.

The engineering tool is a part of the HIMA Smart Safety Platform and adapts modularly

to your project requirements. In addition to its core function, SILworX also offers Industry

4.0 functions for user-specific programming. Benefit from efficient and flexible engineering

solutions for future-proof digitalization of functional safety with added value.

SILworX offers a modular approach.  In addition to its core functions, the programming of

safety controllers, it also offers industry 4.0 features that can be deployed flexibly to meet

the application´s specific requirements. All of these features are safety certified.

Thanks to the new interface external plug-ins such as scripts, programs or functions can

also be integrated into your own automation project.
