SEHA36AT0100 | General Electric Circuit Breaker

Product Description P/N: SEHA36AT0100 Description / Specifications Description The SEHA36AT0100 is a three-pole molded case circuit breaker manufactured by General Electric as part of their Spectra Series. It belongs to the type SEHA category and is designed for three-phase systems. This circuit breaker has a current rating of 100A and is rated for use in electrical systems with a voltage of up to 600V. It offers a standard interrupting capacity of 25kA at 480V and is of bolt-on type. Technical Specifications Part Number SEHA36AT0100 Category Circuit Breaker Subcategory Molded Case Circuit Breaker Product Line Spectra RMS - Standard Trip Style Interchangeable Frame Frame Type SE Amperage 100 A, 70 A, 80 A, 90 A Poles 3 System Voltage 120 Vac, 120/240 Vac, 240 Vac, 277 Vac, 480 Vac, 600 Vac Interrupting Rating * 120 Vac 65 kAIC * 120/240 Vac 65 kAIC * 240 Vac 65 kAIC * 277 Vac 25 kAIC * 480 Vac 25 kAIC * 600 Vac 18 kAIC Trip Function LSI Continuous Current Rating Standard Suitable for Reverse Feed Yes Lug Type TCAL18 Long Time Fixed Yes Short Time Adjustable Yes Instantaneous Adjustable Yes Current Metering No Protective Relays No Special Markings HACR, GSA Not Compliant Information About SEHA36AT0100 The SEHA36AT0100 is a molded case circuit breaker manufactured by General Electric as part of their Spectra Series. It falls under the type SEHA classification and is designed to operate in three-phase electrical systems.

With a current rating of 100A, this circuit breaker is suitable for use in systems with a voltage of up to 600V. Featuring a standard interrupting capacity of 25kA at 480V, the SEHA36AT0100 is equipped to handle typical overcurrent situations. It is of the bolt-on type, facilitating secure mounting in compatible electrical panels or enclosures. Additionally, it is specifically engineered for reverse fed applications, enhancing its versatility in various electrical setups. This circuit breaker is UL listed, indicating compliance with safety standards established by Underwriters Laboratories. It comes complete with an interchangeable RMS trip unit, providing Long-Time, Short-Time, and Instantaneous trip functions. These functions enable precise and reliable protection against overcurrent events. Manufacturer information General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions. IQElectro is not an authorized distributor. QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply.IQElectro sells SURPLUS onlyand DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
