ABB DYTP600A 61430001-ZY Ethernet communication module



The REF 543 feeder terminal is designed for protection, control,

measurement and supervision in medium voltage networks.

The REF 543 feeder terminal can be used with different kinds of switchgear,

including single busbar, double busbar and duplex systems.

The protection functions also support different types of networks, such as, isolated neutral networks,

resonant-earthed networks and partially earthed networks.

The application area also covers medium-sized three phase asynchronous motors as well as

protection and control of shunt capacitor banks used for reactive power compensation.

Single loop granularity - each SCM handles a single channel

Supports hot swap

Mechanical locking slider which turns off field device power and/or output before removal

Field disconnect function which can galvanically separate the field loop wiring from the SCM during

commissioning and maintenance

All SCMs have electronic current limitation

Mechanical keying to prevent insertion of wrong module type after commissioning

24V DC powered through Modulebus

Configurable through parameters

LED indicators on the SCM indicate the operational state of the module.
