GE D20 EME210BASE-T Ethernet Communication Module

The IC693CPU363 is manufactured by GE Fanuc. This module is a controller

from the Series 90-30 of Programmable Logic Controllers (PLC).

This controller is responsible for executing the user program stored within its user memory

as well as managed communication exchanges between compatible

devices such as programming workstations,Human Machine Interface (HMI),

Supervisory Control and Data Acquisition (SCADA),

Databases and other 3rd party hardware and devices.

The IC693CPU363 features a 80386EX processor with clock speed of 25 MHz and

typical scan rate of 0.22 ms per 1K of logic for Boolean contacts.

The embedded memory of this controller amounts to 240KB which is internally partitioned

to accommodate different registers and internal functions.

It has Two (2) serial ports, One (1) port having a physical interface of RJ45

while the other port having a 15-pin sub-D connector,

both supporting RS232 and RS485 communication standards.

It also has a tertiary RS485 port which is situated on the power supply.

All these ports allow download, upload of user program,

perform commissioning tasks and fine tuning of the program.

These ports operate independently and may be configured for simultaneous operation to accommodate

other data exchange functions such as communication with visualization components.

Other communication protocols supported by the IC693CPU363 are Ethernet,

FIP, Profibus, GBC, GCM, GCM+ option modules.

The Bus Interface Unit and I/O modules are enclosed in sturdy, compact aluminum

housings. Bus Interface Unit and I/O modules bolt securely to separate Terminal Blocks,

which provide all field wiring terminals. The I/O Terminal blocks are generic and allow

different I/O module types to be mounted on the same base.  I/O Terminal Blocks are

available with box-type terminals, barrier-type terminals, or wire-to-board connectors.

All Terminal Blocks must be mounted on a DIN rail. The DIN rail, which serves as an

integral part of the grounding system, can also be mounted on a panel.

The individual module datasheets included in the Field Control I/O Modules User's

Manual, which provide specific module wiring information.

Conformance to Standards (GFK-1179). This manual describes the installation

requirements for programmable control products used in industrial environments,

specifically, in situations where compliance to standards or directives from the

Federal Communications Commission, the Canadian Department of

Communications, or the European Union is necessary. The information in this

manual is applicable for GE Fanuc Series 90-70 and Series 90-30 programmable

controller products, Genius I/O products,  and Field Control Distributed I/O and Control products.
