Honeywell 900TER-0001 Digital Input 120/240 VAC (16 channel)

ControlEdge™ is a next generation family of controllers providing secure connectivity

through all levels of process and business functions, optimized operations,

and maintenance efficiencies to meet your diverse automation needs.

These controllers additionally support inherent integration with Experion® systems when needed to deliver a fully cohesive automation solution.

The ControlEdge family of controllers turns data into actionable insight, from edge to enterprise, to help customers improve their bottom line.

Other Modules

In addition to I/O, the following modules are available.

 Scanner 1 module, single port (p.31)

 Scanner 2 Module, dual port (p.32)

 Universal AC Power Supply, 60W (p.4)

 Power Supply 24VDC, 60W (p.4)

 Redundant Switch Module (p.33)

 Power Status Module (p.33)

Database Capacity 900

Control Stations support up to 30,568 signal tags in a user’s configuration database.

Each internal or controller designated tag assigned by the user consumes one of these tags.

In addition, each function block imported from a controller’s database (.cde file) will consume a quantity of signal tags.

The table below indicates the number of tags consumed by each instance of a function block, by type, in a user’s controller configuration.

Benefits

Ability to communicate directly to Ethernet Device Networks.

Use the EIOC to monitor and control Ethernet Devices.

„ Powerful and Scalable. The EIOC allows a huge amount of data coming from Ethernet Devices to be accessed in DeltaV,

and is scalable to fit your needs with licensing based on thenumber of devices you connect.

The EIOC can bring:

z Up to 32.000 signals from 256 Ethernet Devices when using Modbus TCP, EtherNet/IP, or IEC61850 MMS.

z Up to 30.000 signals from 64 Ethernet Devices when using OPC UA client protocol.

z Up to 2000 tags (10 signals per tag) from 256 Ethernet

Devices when using EtherNet/IP Control Tag Integration Protocol.

Introduction

The Ethernet I/O Card (EIOC) provides a platform to access data  from Ethernet devices in the DeltaV™ system.

Ethernet Devices capable of talking Modbus TCP, EtherNet/IP, IEC 61850 MMS (Manufacturing Message Specification),

OPC UA client and EtherNet/IP Control Tag Integration protocols are supported.

The EIOC provides monitoring and control of Ethernet Devices on the Ethernet Device Network via control modules assigned

to and executed in the EIOC. Ethernet Devices like PLCs, Motor Control Centers, drives, switchgear and others can be

controlled directly by the EIOC, independent of a controller.

Insert and Removal of I/O under Power

For ease of maintenance, the ControlEdge HC900 controller

supports removing and inserting I/O modules from the

module rack without removing power from the controller.

Each module is sensed for validity by the controller

and auto-configured on insertion.

Transporting Controller

Configurations and Recipes ControlEdge HC900 controller configuration

files and recipe files developed using Process Control Designer software or Process Control Utilities software may

be placed on a USB memory device and transferred to the controller using prebuilt displays in the station.

Controller configurations and 900 Control Station configuration images may also be copied from the controller

or station onto a USB device for performing maintenance, record keeping or transferring from one system to another.
