Emerson Rosemount 702 Wireless Plunger Arrival Transmitter

Rosemount 3051C Coplanar Pressure Transmitters are the

 industry standard for differential, gage, and absolute pressure

 measurement. The coplanar platform enables seamless

 integration with manifolds, flow, and level solutions.

 ■ Loop Integrity and Plugged Impulse Line Diagnostics detect

 issues that might compromise the integrity of the output

 signal (code DA1).

 ■ Bluetooth® Connectivity enables efficient, reliable, and safe

 configuration and maintenance (code BLE).

 ■ Back-lit Graphical Display with Local Language Capability

 (code M6).

 ■ Safety certification and proof testing (code QT and T9).

Reduced installation time and expense: The DeltaV system’s

S-series I/O interfaces are designed for quick assembly and

error proof maintenance. All carriers snap onto T-DIN rails and

interfaces snap into the I/O slots without the use of any tools.

Each I/O interface has a separate wiring terminal block,

which connects field wiring to the interface. The I/O card can

easily be removed without touching the I/O wiring on the

terminal block. Some I/O cards can also use the fused terminal

block, which is equipped with in-line fuses that can be pulled

to isolate power to the field circuit.

Physical specifications

Material selection

Emerson provides a variety of Rosemount products with various product options

and configurations including materials of construction that can be expected to perform

well in a wide range of applications. The Rosemount product information presented is

intended as a guide for the purchaser to make an appropriate selection for the application.

It is the purchaser’s sole responsibility to make a careful analysis of all process parameters

(such as all chemical components, temperature, pressure, flow rate, abrasives,

contaminants, etc.), when specifying product materials, options, and components for

the particular application. Emerson is not in a position to evaluate or guarantee the

compatibility of the process fluid or other process parameters with the product options,

configuration, or materials of construction selected.
